Nihon Kohden
ECG-3150
ECG-2250
ECG-2350
TEC-8300
TEC-5600
EMS-1052
Bedside Monitor SVM-7500/7600
ECG-3150 | 3-channel interpretive ECG
- Meets IEC60601-2-51 international standard for digital electrocardiographs specifying accuracy and digital filter performance
- 12-lead waveforms can be confirmed at a glance on the angled display
- ECG analysis by ECAPS 12C interpretation program
- Thermal array recorder
- Built-in LAN capability
- ECG data can be reviewed and managed on a PC with optional ECG Viewer software
- A rechargeable battery provides more than 120 minutes of measurement and recording
- Compact and lightweight
ECG-2250 | 6-channel interpretive ECG
- Meets IEC60601-2-51 international standard for digital electrocardiographs specifying accuracy and digital filter performance
- 7-inch backlit color LCD displays all 12-lead ECG waveforms and patient information on one screen
- ECG analysis by ECAPS 12C interpretation program
- Thermal array recorder
- ECG data can be sent to a PC by SD memory card, wired or wireless LAN
- ECG data can be reviewed and managed on a PC with optional ECG Viewer software
- Alphanumeric keyboard for easy data entry.
- Up to 400 ECG files can be saved in the internal memory.
- Compact and lightweight
ECG-2350 | 12-channel interpretive ECG
- 7-inch color LCD displays simultaneous 12-lead ECG waveforms and data more easily
- Adjustable display improves visibility and provides smooth operation
- Meets IEC60601-2-51 international standard for digital electrocardiographs specifying accuracy and digital filter performance
- ECG analysis by ECAPS 12C interpretation program
- ECG data can be transferred to a PC through wireless or wired LAN
TEC-8300 series | Difibrillator
AED, Bluetooth data transfer, and multi-parameter monitoring including 3, 6, 12-lead ECG, SpO2, temperature, and MULTI connector parameters*
*MULTI connector parameters: ETCO2, IBP, temperature
- Biphasic waveform gives more effective defibrillation at lower energy
- Nihon Kohden’s unique ActiBiphasic™ technology provides more efficient defibrillation than conventional biphasic circuits by maintaining constant second phase pulse width for high impedance patients
- AED with disposable pad adapter cable and disposable pads, automatic charging start for hands-free defibrillation, CPR timing sound, and optional voice prompt
- Noninvasive pacing
- NIBP measurement
- 8.4-inch color TFT LCD display
- Nihon Kohden’s advanced ec1 arrhythmia analysis
- Smart CableTM technology – plug and play monitoring
- 12-lead ECG data transmission through mobile network by Bluetooth
- Self-test indicator
Bluetooth is a trademark of the Bluetooth SIG, Inc.
TEC-5600 | Difibrillator
AED, Bluetooth data transfer, 3, 6-lead ECG, SpO2, and ETCO2, NIBP*
* The available functions of the TEC-5600-series models vary. Please contact your sales representatives.
- Faster shock and continuous observation
It takes less than 4 seconds to charge 200J with either AC power or a fully charged new battery. After defibrillation, ECG baseline recovers within 3 seconds. - Continuous VF analysis
ECG waveform can be analyzed even during CPR and energy charging starts before the shock is advised. This helps you deliver faster defibrillation than ever before.
- Biphasic waveform gives more effective defibrillation at lower energy
Nihon Kohden’s unique ActiBiphasic technology provides more efficient defibrillation than conventional biphasic circuits by maintaining constant second phase pulse width for high impedance patients
- Noninvasive pacing
- High power backlit 6.5-inch color TFT LCD display
- Nihon Kohden’s advanced ec1 arrhythmia analysis
- Smart Cable technology – plug and play monitoring
- Onscreen operation guide
- ECG data transmission through mobile network by Bluetooth
- Self-test indicator
Bluetooth is a trademark of the Bluetooth SIG, Inc.
EMS-1052 | Difibrillator
TRANSITIONING BACK TO LIFE
When an every-moment-counts situation occurs in emergency treatment, you need to do everything possible in your power to save the patient’s life. This light and compact device enables you to deliver a fast response to the patient on site. Nihon Kohden’s original innovative technology contributes to a better outcome for the patient and the integrated system for data transmission empowers your team to improve quality of resuscitation.
This is cardiolife EMS.
Features
ECG, SpO2, CO2, NIBP, 12-lead ECG, Synthesized 18-lead ECG, IBP, TEMP, and cardiac output (esCCO). In addition to manual defibrillation, AED mode, cardioversion and pacing are available.
- 6.5 inch color TFT touch panel display
- Long time operation battery
- Quick charging and operation
- Artifact suppressing pads and CPR assist
- Self-test indicator
Bedside Monitor SVM-7500/7600 series
Intuitive touch screen operation
The touch screen provides easy and intuitive operation. Just click the data area for the patient or parameter to see more information or change a setting. Easy operation frees you to focus on your patient.
User-friendly operation
An onscreen guide with helpful illustrations makes it easy to operate the monitor and perform basic tasks even for first time users.
The guide also includes an explanation of abbreviations for parameters, arrhythmias and icons which are found in all Nihon Kohden monitors.
Smooth operation enables you to focus on better patient care.
120 hours of synchronized review data
Up to 120 hours of review data is saved.
Time is synchronized across all review screens so you can easily review an event different points of view. Comprehensive review contributes to decision making for patients.
Interbed gives quick access to check any patient in the network
From any monitor, you can check the vital information and alarm status of any other monitor in the network. With this interbed function, you can immediately check the status of any patient. This leads to better care for all patients.
Reliability, quality and performance
To assure high quality and performance, SVM-7500/7600 bedside monitors are designed and manufactured under the same rigorous standards as all Nihon Kohden products.
Nihon Kohden’s assured quality over the life of the product gives you excellent total cost of ownership and best return on investment.
